Heavy Duty Metal Bearing Bar Steel Grid Serrated Steel Mesh Hot DIP Galvanized Steel Grating
Place of Origin:Cina
Nama Merek:GNEE
Sertifikasi:ISO9001,SGS
Jumlah Pesanan Minimum:10 meter persegi
Price:negotiable
Ketentuan Pembayaran:Bisa dinegosiasikan
Kemampuan Pasokan:100 ton/minggu
Tag:
Detail Produk
Menyoroti:
Gelap baja tugas berat
,grating mesh baja galvanis
,batang bantalan baja bergerigi
Deskripsi Produk
Jeruji Baja Logam Tugas Berat Kisi Baja Baja Bergerigi Hot DIP Galvanized
Spesifikasi Kapasitas Beban
| Ukuran Batang Penahan (mm) | Tersedia Untuk Platform Perawatan (UDL=2.5kPa) | Tersedia Untuk Pejalan Kaki (UDL=3kPa) | Tersedia Untuk Pejalan Kaki yang Ramai (UDL=4kPa) | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 30mm | 40mm | 60mm | 30mm | 40mm | 60mm | 30mm | 40mm | 60mm | |
| 30x3 | 1190 | 1110 | 1000 | 1140 | 1060 | 960 | 1060 | 980 | 890 |
| 25x3 | 1410 | 1310 | 1180 | 1350 | 1250 | 1130 | 1250 | 1170 | 1050 |
| 32x3 | 1700 | 1580 | 1430 | 1620 | 1510 | 1350 | 1510 | 1400 | 1270 |
| 40x3 | 2010 | 1870 | 1690 | 1920 | 1780 | 1610 | 1780 | 1660 | 1500 |
| 20x5 | 1350 | 1260 | 1140 | 1290 | 1200 | 1090 | 1200 | 1120 | 1010 |
| 25x5 | 1600 | 1490 | 1350 | 1530 | 1420 | 1290 | 1420 | 1320 | 1200 |
| 32x5 | 1930 | 1790 | 1620 | 1840 | 1710 | 1550 | 1710 | 1590 | 1440 |
| 40x5 | 2280 | 2120 | 1920 | 2180 | 2030 | 1830 | 2030 | 1890 | 1700 |
Spesifikasi Jeruji Baja
Ukuran batang penahan: 40 X 5mm
Jarak batang penahan: 25mm
Jarak batang silang: 100mm
Jenis jeruji: Batang penahan bergerigi
Spesifikasi Jeruji Baja Reguler
| Material | Baja ringan / baja karbon / baja tahan karat Q235B, ASTM A36, S275JR dll. |
| Spesifikasi |
|
| Standar Galvanisasi | ISO 1461; ASTM A123; GB/T13912:2002 |
| Paket | Paket layak laut |
| Standar Produksi | YT/T 4001.1-2007; BS4592-1:1995; AMSI/NAAMM(MBG531-2000); AS1657-1992 |
| MOQ | 100 pcs |
Ringkasan Produk
Jeruji Baja Logam Tugas Berat Kisi Baja Baja Bergerigi Hot DIP Galvanized Spesifikasi Kapasitas Beban Ukuran Batang Penahan (mm) Tersedia Untuk Platform Perawatan (UDL=2.5kPa) Tersedia Untuk Pejalan Kaki (UDL=3kPa) Tersedia Untuk Pejalan Kaki yang Ramai (UDL=4kPa) 30mm 40mm 60mm 30mm 40mm 60mm 30mm ...
