Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads
Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads
Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

Gambar besar :  Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

Detail produk:
Tempat asal: CINA
Nama merek: GNEE
Sertifikasi: SGS
Syarat-syarat pembayaran & pengiriman:
Harga: negotiable
Kemasan rincian: Pengemasan layak laut, yaitu baki kayu atau baja dengan strip baja, dll
Waktu pengiriman: 5-9 hari kerja
Syarat-syarat pembayaran: Bisa dinegosiasikan
Menyediakan kemampuan: 100 ton/minggu
Kontak

Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

Deskripsi
Menyoroti:

galvanized steel stair treads

,

powder-coated steel grating treads

,

metal plank grating stair treads

Metal Plank Grating Stair Treads
Galvanized Steel Treads / Powder-Coated Steel Treads / Wide Range of Stair Treads
GNEE Steel specializes in the production of steel grating, steel grate and frame, trench grate, kerb grate, storm pits cover, access cover grate, manhole covers, side entry grate, steel stair, steel ball stanchion, steel railing, aluminium grating and other light steel structure products. The company has a complete computer-aided design system that can provide users with perfect steel grating layout design. The processing technology is superb and the product quality is excellent.
Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads 0
Stair treads steel grating is made by bearing bar and cross bar according to the flat-steel weft arrangement, in high-pressure spacing on resistance welder welded by cutting, incision, opening, overlock process such as processing and into customer requirements finished products. It's usually used in industrial construction projects. We have 4 types to choose from: welded fixing stair treads, clip fixing galvanized stair treads, and checker plate stair treads.
Product Specifications
Name Stainless Steel Grating
Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1 1/2''x1/8'' etc
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Material Grade ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400, Mild steel & Low carbon steel, etc
Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
Standard China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),
UK: BS4592-1987, Australia: AS1657-1985,
Germany: DIN24537-1-2006, Japan: JIS
Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads 1 Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads 2 Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads 3
