G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway

G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway
G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway
G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway

Gambar besar :  G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway

Detail produk:
Tempat asal: CINA
Nama merek: GNEE
Sertifikasi: SGS
Syarat-syarat pembayaran & pengiriman:
Harga: negotiable
Kemasan rincian: Pengemasan layak laut, yaitu baki kayu atau baja dengan strip baja, dll
Waktu pengiriman: 5-9 hari kerja
Syarat-syarat pembayaran: Bisa dinegosiasikan
Menyediakan kemampuan: 100 ton/minggu
Kontak

G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway

Deskripsi
Menyoroti:

galvanized welded steel grating

,

serrated steel grating walkway

,

steel structure metal grating

G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway
Galvanized Welded Metal Steel Grating, also known as bar grating or metal grating, is an open grid assembly of metal bars, in which the bearing bars, running in one direction, are spaced by rigid attachment to cross bars running perpendicular to them or by bent connecting bars extending between them, which is designed to hold heavy loads with minimal weight. It is widely used as floors, mezzanines, stair treads, fencing, trench covers and maintenance platforms in factories, workshops, motor rooms, trolley channels, heavy loading areas, boiler equipment and heavy equipment areas, etc.
G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway 0
Product Specifications
Product Name Steel Bar Grating
Material Mild Steel (Low Carbon Steel), S235, S275JR, A36, or Stainless Steel SS304, SS316 etc, Aluminum 3003, 5052
Surface treatment Hot dipped galvanized, polished or untreated
Bearing bar (width x thickness) 25x3, 25x4, 30x3, 30x4, 30x5, 32x5, 40x5, 50x5, 75x10mm
Bearing bar pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40, 41, 60mm. US standard: 1"x3/16", 11/4"x3/16", 11/2"x3/16", 1"x 1/4", 11/4"×1/4", 11/2"x 1/4" etc.
Cross bar pitch 38, 50, 76, 100, 101.6mm or customized
Standard Specifications
Pitch of Bearing bar Cross-bar Pitch 20×3 25×3 32×3 40×3 20×5 25×5
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100
30 50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100
40 50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
60 50 G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Pitch of Bearing bar Cross-bar Pitch 32×5 40×5 45×5 50×5 55×5 60×5
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100
30 50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100
40 50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50
Applications
Working Platform, Handrail Infill, Walkway, Bridge decking, Stair Treads, Transformer Reservoir, Trench Cover, Ceiling, Grating Fence, Sunshade Panels
G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway 1 G325/60/50, G323/40/100 Galvanized Welded Metal Steel Grating for Steel Structure Walkway 2

Label:

serrated bar grating,

serrated steel bar grating,

galvanized serrated grating
