Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating

Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating
Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating
Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating

Gambar besar :  Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating

Detail produk:
Tempat asal: CINA
Nama merek: GNEE
Sertifikasi: SGS
Syarat-syarat pembayaran & pengiriman:
Harga: negotiable
Kemasan rincian: Pengemasan layak laut, yaitu baki kayu atau baja dengan strip baja, dll
Waktu pengiriman: 5-9 hari kerja
Syarat-syarat pembayaran: Bisa dinegosiasikan
Kontak

Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating

Deskripsi
Menyoroti:

customizable circular steel walkway grating

,

galvanized serrated steel grating

,

platform bridge steel grating

Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating
Introducing our innovative steel grating product, featuring a robust serrated bearing bar, crafted with precision for superior performance. Thanks to its smart and efficient structural design, this remarkable grating is the go-to choice for applications demanding high load-bearing prowess or aesthetic appeal. Produced from a specified size of serrated steel, this grating undergoes a series of meticulous processes-slotting, inserting, welding, and finishing-culminating in a product capable of handling substantial loads. It stands as a trusted solution for heavy-duty industrial platforms, offering a significant safety margin. Surface treatments are versatile, including galvanizing, painting, or dipping, tailored to your needs.
Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating 0 Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating 1
Specification
Product Name Customized Anti-slip Serrated Steel Grating
Material Mild Steel (Low Carbon Steel), S235, S275JR, A36, or Stainless Steel SS304, SS316 etc.
Surface treatment Hot dipped galvanized, polished or untreated
Grate size as customer's request
Bearing bar width x thickness 25x3, 25x4, 30x3, 30x4, 30x5, 32x5, 40x5, 50x5,...75x10mm
US standard: 1"x3/16", 11/4"x3/16", 11/2"x3/16", 1"x 1/4", 11/4"×1/4", 11/2"x 1/4" etc.
Bearing bar pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40, 41, 60mm.
Cross bar pitch 38, 50, 76, 100, 101.6mm or custom
Technical Specifications
Pitch of Bearing bar Cross-bar Pitch Specification of bearing bar (width x thickness)
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100
50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100
50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
60 50 G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Pitch of Bearing bar Cross-bar Pitch Specification of bearing bar (width x thickness)
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100
50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100
50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50
Note: We offer the flexibility of customized sizes.
Platform Bridge Use Customizable Circular Galvanized Serrated Steel Walkway Grating 2

Label:

serrated bar grating,

serrated steel bar grating,

galvanized serrated grating
