19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms

19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms
19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms 19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms 19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms

Gambar besar :  19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms

Detail produk:
Nama merek: Gnee
Sertifikasi: ISO9001
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 2 pcs
Kemasan rincian: Perbaiki dengan sabuk logam Pengepakan dengan palet, bungkus luar dengan film plastik tahan air Fini
Waktu pengiriman: Dikirim dalam 20 hari setelah pembayaran
Menyediakan kemampuan: 300000 meter persegi/meter persegi per bulan
Kontak

19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms

Deskripsi
Menyoroti:

19W4 Steel Bar Grating

,

Aluminum Metal Grating

,

Catwalk Deck Floor Grating

Heavy Duty 19W4 Aluminum, Galvanized Steel, Stainless Steel Bar Grating
Our high-strength steel bar grating features a firm structure and is available in carbon steel, aluminum steel, or stainless steel. Manufactured using various methods including welded, press-locked, swage-locked, and riveted techniques. Available in both smooth and serrated surface patterns, these gratings offer versatile solutions for stair treads, walkways, platforms, floors, covers, and heavy-duty construction applications.
19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms 0 19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms 1
Standard Specifications
Pitch of Bearing Bar Cross-bar Pitch Specification of Bearing Bar (width×thickness)
30 100 G203/30/100 | G253/30/100 | G323/30/100 | G403/30/100 | G205/30/100 | G255/30/100
50 G203/30/50 | G253/30/50 | G323/30/50 | G403/30/50 | G205/30/50 | G255/30/50
40 100 G203/40/100 | G253/40/100 | G323/40/100 | G403/40/100 | G205/40/100 | G255/40/100
50 G203/40/50 | G253/40/50 | G323/40/50 | G403/40/50 | G205/40/50 | G255/40/50
60 50 G253/60/50 | G253/60/50 | G403/60/50 | G205/60/50 | G255/60/50
Pitch of Bearing Bar Cross-bar Pitch Specification of Bearing Bar (width×thickness)
30 100 G325/30/100 | G405/30/100 | G455/30/100 | G505/30/100 | G555/30/100 | G605/30/100
50 G325/30/50 | G405/30/50 | G455/30/50 | G505/30/50 | G555/30/50 | G605/30/50
40 100 G325/40/100 | G405/40/100 | G455/40/100 | G505/40/100 | G555/40/100 | G605/40/100
50 G325/40/50 | G405/40/50 | G455/40/50 | G505/40/50 | G555/40/50 | G605/40/50
60 50 G325/60/50 | G405/60/50 | G455/60/50 | G505/60/50 | G555/60/50 | G605/60/50
Material Specifications
Materials:
Q195, Q235, Q235B / 304, 316 Stainless Steel
Bearing Bar:
  • 25×3, 25×4, 25×4.5, 25×5
  • 30×3, 30×4, 30×4.5, 30×5
  • 32×5, 40×5, 50×5, 65×5
  • 75×6, 75×10---100×10mm
  • I bar: 25×5×3, 30×5×3, 32×5×3, 40×5×3
  • US standard: 1"×3/16", 1 1/4"×3/16", 1 1/2"×3/16"
  • 1"×1/4", 1 1/4"×1/4", 1 1/2"×1/4"
  • 1"×1/8", 1 1/4"×1/8", 1 1/2"×1/8"
Bearing Bar Pitch:
12.5, 15, 20, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm
US Standard:
19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2
Twisted Cross Bar Pitch:
38.1, 40, 50, 60, 76, 80, 100, 101.6, 120mm, 2" & 4"
Steel Grade:
ASTM A36, A1011, A569, Q235, S235JR, S275JR, SS304, Mild steel & Low carbon steel
Surface Treatment:
Black, self color, hot dip galvanized, painted, spray coating
Grating Style:
Plain / Smooth, Serrated / teeth, I bar, serrated I bar
19W4 Aluminum Steel Bar Grating for Catwalk Deck and Heavy Duty Walkway Platforms 2

Label:

heavy duty bar grating,

metal drain grates,

industrial floor grates
