Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use

Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use
Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use

Gambar besar :  Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use

Detail produk:
Nama merek: Gnee
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 2 buah
Kemasan rincian: Perbaiki dengan sabuk logam Pengepakan dengan palet, bungkus luar dengan film plastik tahan air Fini
Waktu pengiriman: Dikirim dalam 20 hari setelah pembayaran
Menyediakan kemampuan: 300000 Meter Persegi/Meter Persegi per Bulan
Kontak

Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use

Deskripsi
Menyoroti:

Polish Serrated Surface Bar Grating

,

Standard Stainless Steel Grating

,

Customizable Sizes Steel Grating

Polish Serrated Surface Standard Stainless Steel Bar Grating
Stainless steel grating is regarded as industrial grade bar grating, which is extremely strong, durable, and corrosive resistant for all load-bearing applications. It is primarily used for pedestrian and light vehicle traffic in hotel and commercial settings.
Product Specifications
Available Materials
  • Q235 / Stainless Steel / Aluminium / Carbon Steel / Low-carbon Steel
Material Standards
  • ASTM A36, A1011, A569, Q235, S275JR
  • Stainless Steel 304/316
  • Mild Steel & Low Carbon Steel
Bar Types
  • Bearing Bar: Flat Bar / I Bar / Serrated Bar
  • Crossbar: Twisted Bar / Round Bar / Flat Bar
Surface Treatments
  • Untreated (Black)
  • Hot-dipped Galvanized
  • Powder-coated
  • Electroplated
  • Painting
  • Custom treatments available per customer requirements
Grating Styles
  • Plain / Smooth
  • Serrated / Teeth
  • I Bar
  • Serrated I Bar
Galvanizing Standards
  • China: GB/T13912
  • USA: ASTM (A123)
  • UK: BS729
International Standards
  • China: YB/T 4001.1-2007
  • USA: ANSI/NAAMM (MBG531-88)
  • UK: BS4592-1987
  • Australia: AS 1657-1988
  • Japan: JJS
Customization Available: Special materials, high zinc coating, and new styles can be customized according to your requirements.
Technical Specifications
Bearing Bar Size: 20×3 | 25×3 | 32×3 | 40×3 | 20×5 | 25×5
Bearing Bar Pitch Crossbar Pitch G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
30 50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100
40 50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100
60 50 / G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Bearing Bar Size: 32×5 | 40×5 | 45×5 | 50×5 | 55×5 | 60×5
Bearing Bar Pitch Crossbar Pitch G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
30 50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100
40 50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50
Applications
Our stainless steel bar grating is widely used in various industrial and commercial applications including:
  • Flooring, Catwalks, and Mezzanines/Decking
  • Stair Treads and Ramps
  • Fencing and Dock Applications
  • Trench Covers and Drainage Pit Covers
  • Maintenance Platforms and Pedestrian Areas
  • Factory and Workshop Flooring
  • Motor Rooms and Trolley Channels
  • Heavy Loading Areas and Boiler Equipment
  • Heavy Equipment Areas
We are a professional factory that designs and manufactures standard steel grating and provides custom solutions according to client requirements.
Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use 0 Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use 1 Polish Serrated Surface Standard Stainless Steel Bar Grating with Customizable Sizes for Industrial Use 2
